High-Performance, Modular Bidirectional, Regenerative
Programable DC Power System
The Sorensen™ Modular intelligent-Bidirectional Energy AMplified (Mi-BEAM) Series is the newest addition to the AMETEK Programmable Power portfolio of high-power testing solutions. The new Mi-BEAM Series features full DC source and sink capabilities with power levels from 12 kW up to 37 kW. The Mi-BEAM Series is fully scalable up to 1.2 MW with parallel systems. The available voltage ranges of 600 V, 1,500 V, and 2,000 VDC in a 4U rack height chassis provide full power up to +/-150 A within a single system.
Features Complete solution - battery test, simulation, & solar array simulator software included
Highest power density up to 37 kW in 4U rack height (9.25 kW/U)
Fastest and cleanest power available
Fastest transient response
Low output ripple and noise
Longest manufacturer-based reliability guarantee, 5-year warranty
Parallel system power up to 1.2 MW
Output voltage up to 2,000 V
Bidirectional output current up to ±150 A, up to ±4,800 A in parallel
True extended autoranging output
Regenerative to 95%
Color touch panel user interface
Seamless transition between course and sink
Built-in islanding detection
The Mi-BEAM Series can be operated from the intuitive, front panel touchscreen, which enables the user to easily set up, control, and monitor the Output Programming Parameters, Supervisory and Set Point limits, Measurements, and System Settings. Additionally, a variety of standard communication control interfaces are available, including LAN, USB, and RS-232. (Optional IEEE-488).
If you would like to receive a quote or ask further questions about Ametek's Mi-BEAM Series, please let us know!
